APC Smart-UPS SRT 5000VA RM - UPS rack-mountable / external - AC 208/230 V - 4500 Watt - 5000 VA - Ethernet 10/100 USB - 3U - black
SKU: SRT5KRMXLW-HW
Quickfind code : 1057136
Product highlights
- Battery: 5year(s)
- Product line: APC Smart-UPS SRT
- AC 208/230V
- Power Capacity 5000VA
Product Description
Text and mimic diagrams that display modes of operation, system parameters and alarms. Connect the device to a network using a 10 or 100 BaseT connection.
Patent-pending operating mode that bypasses unused electrical components in good power conditions to achieve very high operating efficiency without sacrificing any protection. Provides early-warning fault analysis on batteries enabling timely preventive maintenance.
Key Product Info
- LCD graphics display
- 10/100 BaseT Connection
- Green mode
- Battery failure notification
Product Features
- LCD graphics display
Text and mimic diagrams that display modes of operation, system parameters and alarms. - 10/100 BaseT Connection
Connect the device to a network using a 10 or 100 BaseT connection. - Green mode
Patent-pending operating mode that bypasses unused electrical components in good power conditions to achieve very high operating efficiency without sacrificing any protection. - Battery failure notification
Provides early-warning fault analysis on batteries enabling timely preventive maintenance.
What's in the box?
- CD with software, Documentation CD, Installation guide, Rack mounting hardware, Rack Mounting support rails, Removable support feet, Temperature Probe, User Manual, Warranty card, Web/SNMP Management Card
Specification
Battery
|
Number of batteries supported
|
1 |
|---|---|
|
Battery recharge time
|
1.5 h |
|
Typical backup time at full load
|
4 min |
|
Battery Technology
|
Sealed Lead Acid (VRLA) |
|
Battery type
|
APCRBC140 |
|
Typical backup time at half load
|
11.8 min |
Ports & interfaces
|
USB 2.0 ports quantity
|
1 |
|---|---|
|
AC outlets quantity
|
- |
|
Ethernet LAN (RJ-45) ports
|
3 |
|
AC outlet types
|
Hard Wire 3-wire (2PH + G) |
Power
|
Emergency Power Off (EPO)
|
Y |
|---|---|
|
Output operation voltage (min)
|
220 V |
|
Output power
|
4500 W |
|
Surge energy rating
|
480 J |
|
Output operation voltage (max)
|
240 V |
|
Power supply input frequency
|
40/70 Hz |
|
Input operation voltage (max)
|
275 V |
|
Input operation voltage (min)
|
100 V |
|
Output power capacity
|
5000 VA |
|
Efficiency
|
93.8 % |
Performance
|
LED indicators
|
Y |
|---|---|
|
Number of phases
|
3 |
|
UPS topology
|
Double-conversion (Online) |
Design
|
Rack mounting
|
3U |
|---|---|
|
Form Factor
|
Rackmount |
|
Colour of product
|
Black |
|
International Protection (IP) code
|
IP20 |
Certificates
|
Certification
|
REACH, CE, CE Mark, CSA C22.2 No.107.3-05, EAC, EN/IEC 62040-1, EN/IEC 62040-2, FCC Part 15 Class A, IRAM, NOM, RCM, UL |
|---|---|
|
RoHS compliance
|
Y |
Weight & dimensions
|
Package weight
|
68040 g |
|---|---|
|
Weight
|
55790 g |
|
Package depth
|
960 mm |
|
Package width
|
610 mm |
|
Package height
|
330 mm |
|
Depth
|
719 mm |
|
Width
|
432 mm |
|
Height
|
130 mm |
Operational conditions
|
Non-operating altitude
|
0 - 15000 m |
|---|---|
|
Operating temperature (T-T)
|
0 - 40 ?C |
|
Storage relative humidity (H-H)
|
0 - 95 % |
|
Operating relative humidity (H-H)
|
0 - 95 % |
|
Storage temperature (T-T)
|
-15 - 45 ?C |
|
Operating altitude
|
0 - 3000 m |
